Docks take a beating. BPS Laminated Dock Bumpers are weather-resistant, straightforward to install, and built for the long haul - protecting dock equipment, building walls, and truck cargo from costly damage.
Our market leading dock bumpers are weather resistant, easily installed and long lasting to protect dock equipment, building walls and truck cargo from potential damage.
Bumper projection should be specified at not less than 100mm. For recessed docks or special applications, additional projection may be required. All laminated dock bumpers are assembled with two 75mm x 75mm x 6mm thick steel angles. The angles are fastened with threaded rod and nut. All exposed metal parts are factory painted. We recommend all bumpers to be installed 25mm to 50mm below dock level. Use 20mm or 16mm expansion bolts with a minimum length of 75mm.
Standard dock bumpers handle most loading bay environments effectively. But for distribution centres and logistics hubs where docking movements happen dozens or even hundreds of times per day, a more robust solution is required. Laminated dock bumpers are the premium answer to extreme-duty loading bay protection.
Laminated dock bumpers are constructed from multiple layers of rubber bonded together, often with fabric or steel reinforcement between layers. This laminated construction gives them significantly greater impact absorption and resilience than single-piece moulded bumpers. They are typically larger, heavier, and designed to withstand the most punishing docking environments. Like standard loading dock bumpers, they mount to the bay face using steel plates and heavy-duty fixings.
Health and safety consultants typically specify laminated dock bumpers for high-throughput facilities: major parcel distribution centres, supermarket regional distribution hubs, and cold-store operations where vehicle movements are constant. They are also common in environments handling oversized or heavy vehicles.
The layered construction absorbs and distributes impact forces more effectively, extending both bumper life and the structural integrity of the bay. Replacement cycles stretch well beyond those of standard units, reducing total cost of ownership. In high-traffic environments, this longevity makes them a cost-effective investment despite a higher upfront price.
Laminated dock bumpers are heavier and require robust mounting. Ensure the building’s structure can support the weight and that steel backing plates are correctly specified. Check whether installation is included or if a separate contractor is required. For facilities covered by PAS 13 assessments, confirm the product’s impact rating meets the specification. Always compare total cost of ownership against standard rubber dock bumpers rather than just the unit price.
